Edison Fuses MCL3 - Midget Fuse 3A 600V (100kA AIC)

Edison Fuses MCL3 is a midget low-voltage fuse designed for circuit protection in industrial electrical systems. It features a 600V AC/DC voltage rating and 3A current rating, housed in a compact 1" x 0.406" x 0.406" (25.4mm x 10.3mm x 10.3mm) ceramic body with 100kA interrupting capacity at rated voltage. The fuse meets industry standards for midget-class protection devices with its single-barrel construction and 0.41" (10.4mm) diameter, suitable for control circuits, transformers, and motor branch circuits requiring precise overcurrent protection.

Key Features & Specifications

• Type: Midget low-voltage current-limiting fuse
• Voltage Rating: 600V AC/DC
• Current Rating: 3A
• Dimensions: 1" L x 0.406" W x 0.406" H (25.4mm x 10.3mm x 10.3mm)
• Standards: UL/CSA recognized
• Applications: Control circuits, instrumentation, small motor protection
• AIC rating: 100kA@600V
• Class Rating: Midget
• Barrels: 1
• Diameter: 0.41" (10.4mm)
• Weight: 1.001 lb

Product Identification

• UPC: 782634420132
• GTIN: 00782634000000
