Edison Fuses MCL20 - Midget Fuse 20A 600V (100kA AIC)

Edison Fuses MCL20 is a midget low-voltage fuse designed for circuit protection in industrial electrical systems. It features a 600V AC/DC voltage rating and 20A current rating, with a compact 1" x 0.406" x 0.406" (25.4mm x 10.3mm x 10.3mm) ceramic body construction weighing 1.001 lb. This UL-recognized fuse meets 100kA interrupting capacity at 600V, complying with industry safety standards for overcurrent protection in motor control centers, transformers, and power distribution equipment.

Key Features & Specifications

• Type: Midget class low-voltage current-limiting fuse
• Voltage Rating: 600V AC/DC
• Current Rating: 20A
• Dimensions: 1" L x 0.406" W x 0.406" H (25.4mm x 10.3mm x 10.3mm)
• Diameter: 0.41" (10.4mm)
• Standards: UL 248-14 recognized
• Applications: Motor controls, transformers, industrial power distribution
• AIC rating: 100kA@600V
• Barrels: 1
• Weight: 1.001 lb
• Class Rating: Midget

Product Identification

• UPC: 78263442020
• GTIN: 00782634420200
