Edison Fuses MCL2 - Midget Fuse 2A 600V (100kA AIC)

Edison Fuses MCL2 is a midget low-voltage fuse designed for circuit protection in industrial electrical systems. It features a 600V AC/DC voltage rating with a 2A current rating and a compact 1" x 0.406" x 0.406" (LxWxH) ceramic body construction. The fuse meets industry standards with a 100kA interrupting capacity at 600V and is commonly used in control panels, transformers, and motor protection circuits.

Key Features & Specifications

• Type: MCL series ceramic-body midget fuse
• Voltage Rating: 600V AC/DC
• Current Rating: 2A
• Dimensions: 1" L x 0.406" W x 0.406" H (25.4mm x 10.3mm x 10.3mm)
• Weight: 1.001 lb
• Diameter: 0.41" (10.4mm)
• Class Rating: Midget
• Barrels: 1
• AIC Rating: 100kA @ 600V
• Standards: UL/CSA recognized
• Applications: Industrial control circuits, transformers, motor protection

Product Identification

• UPC: 782634420125
• GTIN: 00782634420125
