Edison Fuses MCL15 - Midget Fuse 15A (100kA AIC @600V)

Edison Fuses MCL15 is a low-voltage midget fuse designed for circuit protection in industrial electrical systems. Rated for 600V AC/DC with a 15A current capacity, it provides reliable overcurrent protection with a 100kA interrupting rating at 600V. The compact 1-inch long fuse features a durable cylindrical design with 0.406-inch width/height dimensions and 0.41-inch diameter, weighing 1.001 lb. Compliant with industry standards for midget fuses, it's commonly used in control panels, motor circuits, and power distribution equipment requiring space-efficient protection.

Key Features & Specifications

• Type: MCL series midget fuse, single-barrel construction
• Voltage Rating: 600V AC/DC
• Current Rating: 15A
• Dimensions: 1" L × 0.406" W × 0.406" H (25.4mm × 10.3mm × 10.3mm)
• Standards: Midget fuse class, 100kA AIC at 600V
• Applications: Industrial control panels, motor protection circuits, power distribution
• Diameter: 0.41" (10.4mm)
• Weight: 1.001 lb (0.454 kg)
• AIC rating: 100kA@600V
• Class Rating: Midget
• Barrels: 1

Product Identification

• UPC: 782634420194
• GTIN: 00782634420194
