Edison Fuses MCL1.5 - Midget Fuse 1.5A (100kA@600V Interrupt Rating)

Edison Fuses MCL1.5 is a midget-class low-voltage fuse designed for circuit protection in industrial electrical systems. Rated for 600V AC/DC applications with a 1.5A current capacity, it provides reliable overcurrent protection with a 100kA interrupting rating at 600V. The compact fuse measures 1" x 0.406" x 0.406" (25.4mm x 10.3mm x 10.3mm) with a 0.41" (10.4mm) diameter, constructed as a single-barrel design weighing 1.001 lb. Compliant with industry standards for midget fuses, it is commonly used in control panels, motor circuits, and transformer protection applications.

Key Features & Specifications

• Type: MCL series midget fuse, single-barrel construction
• Voltage Rating: 600V AC/DC
• Current Rating: 1.5A
• Dimensions: 1" L x 0.406" W x 0.406" H (25.4mm x 10.3mm x 10.3mm)
• Standards: Midget fuse class compliant
• Applications: Industrial control panels, motor circuits, transformer protection
• AIC rating: 100kA@600V
• Diameter: 0.41" (10.4mm)
• Weight: 1.001 lb

Product Identification

• UPC: 78263442011
• GTIN: 00782634420118
