Edison Fuses MCL1 - Midget Fuse 1A 600V (100kA AIC Rating)

Edison Fuses MCL1 is a midget-class low-voltage fuse designed for circuit protection in industrial electrical systems. Rated for 600V AC/DC operation with a 1A current capacity, it provides reliable overcurrent protection with a 100kA interrupting rating at 600V. The compact cylindrical design measures 1" x 0.406" x 0.406" (LxWxH) with a 0.41" diameter, constructed to UL/CSA standards for safety compliance. This MCL-series fuse is commonly used in control panels, motor circuits, and transformer protection applications where space-constrained installations require midget-class components.

Key Features & Specifications

• Type: Midget-class low-voltage fuse (MCL series)
• Voltage: 600V AC/DC
• Current: 1A
• Dimensions: 1" x 0.406" x 0.406" (LxWxH)
• Diameter: 0.41"
• Weight: 1.001 lb
• Barrels: 1
• AIC rating: 100kA@600V
• Class Rating: Midget
• Standards: UL/CSA compliant
• Applications: Control panels, motor circuits, transformer protection

Product Identification

• UPC: 78263442010
• GTIN: 00782634420101
