Bussmann LPNRK35SP - RK1 Time-Delay Fuse 35A 250V (300kA AIC)

The Bussmann LPNRK35SP is a Low-Peak time-delay fuse from Eaton's Low Voltage family, engineered to provide superior short-circuit and overload protection for electrical circuits. It features a 35A current rating and a 250V voltage rating, with an impressive 300,000A interrupting capacity at rated voltage to safely clear high-level faults. The fuse is constructed as a single-barrel RK1 class device with a 0.81-inch diameter and a robust design weighing 5.19 lb, ensuring reliable performance under demanding conditions. This fuse complies with industry standards for current-limiting fuses, providing enhanced equipment protection. It is typically applied in industrial control circuits, motor branch circuits, and feeder circuits where time-delay characteristics and high interrupting ratings are required.

Key Features & Specifications

• Type: Low-Peak time-delay fuse, current-limiting, single barrel construction
• Voltage Rating: 250V AC
• Current Rating: 35A
• Dimensions: 0.81-inch diameter
• Standards: RK1 class rating
• Applications: Industrial control circuits, motor branch circuits, feeder protection
• AIC rating: 300kA @ 250V
• Class Rating: RK1
• Barrels: 1
• Weight: 5.19 lb
• Item Subcategory: Low Voltage
• Family: Low-Peak
• Manufacturer: Eaton
