Bussmann LPJ-60SPI - Class J Time-Delay Fuse 60A (300kA AIC @600V)

The Bussmann LPJ-60SPI is a Class J time-delay fuse designed to provide reliable circuit protection for industrial power distribution systems while offering high interrupting capacity. It features a 600V AC voltage rating with a 60A current rating and delivers 300kA interrupting capacity at 600V AC for superior fault current protection. The fuse construction includes a single-barrel design measuring 2-3/8 inches in length with a 1.06-inch diameter, weighing 1.18 lb, and utilizes Eaton's Low-Peak technology to limit let-through current while maintaining time-delay characteristics. This fuse meets CE, UL Special Purpose Guide JFHR, and CSA Class 1422-02 certification requirements, ensuring compliance with industrial safety standards. Typical applications include motor branch circuit protection, feeder circuit protection, and industrial control panel applications where high fault current interruption is critical.

Key Features & Specifications

• Type: Class J time-delay fuse, Low-Peak technology, single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 60A
• Dimensions: 2-3/8 inches length, 1.06 inches diameter
• Standards: CE/UL-Special Purpose Guide JFHR/CSA Class 1422-02
• Applications: Motor branch circuit protection, feeder circuits, industrial control panels
• AIC rating: 300kA@600V AC
• Class Rating: J
• Barrels: 1
• Weight: 1.18 lb
• Family: Low-Peak
• Country of Origin: Mexico

Product Identification

• UPC: 051712626408
• GTIN: 00051712626408
