Edison Fuses LCL750 - Class L Current-Limiting Fuse 750A (200kA@600V Interrupt Rating)

Edison Fuses LCL750 is a low-voltage current-limiting fuse designed for high-interrupting capacity circuit protection in industrial power distribution systems. Rated for 600V AC/DC operation with a 750A current rating, this Class L fuse features a single-barrel construction with a 2.5-inch diameter and compact 0.001in³ dimensions, weighing 3 lb for robust performance. It meets industry standards with a 200kA interrupting capacity at 600V, providing reliable short-circuit protection for motor control centers, service entrance equipment, and industrial switchgear applications.

Key Features & Specifications

• Type: Class L current-limiting fuse, single-barrel design
• Voltage Rating: 600V AC/DC
• Current Rating: 750A
• Dimensions: 0.001in (L) x 0.001in (W) x 0.001in (H)
• Weight: 3 lb
• Diameter: 2.5 inches
• AIC Rating: 200kA @ 600V
• Standards: UL/CSA listed for industrial applications
• Applications: Motor control centers, switchgear, power distribution panels

Product Identification

• UPC: 78263460575
• GTIN: 00782634605751
