Edison Fuses LCL3500 - Class L Fuse 3500A@600V (200kA AIC)
Regular price
$3,443.11
$3,443.11
Regular price
$7,852.27
$7,852.27
Sale price
$3,443.11
$3,443.11
Save $4,409.16
/
- Low stock - 5 items left
- Backordered, shipping soon
Edison Fuses LCL3500 is a low-voltage fuse designed for high-current circuit protection in industrial power distribution systems. This Class L fuse features a 600V AC rating and 3500A current capacity, with a robust single-barrel construction measuring 5.75" in diameter and weighing 8 lb. It meets stringent industry standards with a 200kA interrupting capacity at 600V, ensuring reliable protection against short circuits. The LCL Series fuse is engineered for demanding applications including switchgear, motor control centers, and industrial power panels where high fault current protection is critical.
Key Features & Specifications
Key Features & Specifications
- Type: Class L low-voltage current-limiting fuse, single barrel design
- Voltage Rating: 600V AC
- Current Rating: 3500A
- Dimensions: 5.75" diameter
- Standards: UL/CSA listed
- Applications: Industrial power distribution, switchgear, MCCs
- AIC rating: 200kA@600V
- Class Rating: L
- Weight: 8 lb
- Barrels: 1
- UPC: 78263460535
- GTIN: 00782634605355
