Bussmann KTS-R-1 - RK1 Class Time-Delay Fuse 1A 600V (200kA AIC)

Bussmann KTS-R-1 is a current-limiting fuse designed for industrial circuit protection applications requiring high interrupting capacity. This 600V AC/DC rated fuse features a 1A current rating with 200kA interrupting capacity at 600V, providing reliable short-circuit protection in demanding environments. The fuse construction utilizes a single-barrel design with RK1 class time-delay characteristics, housed in a compact 5-inch long by 0.81-inch diameter package weighing 1 lb. Engineered to meet industry standards for low-voltage protection, this LIMITRON series fuse is commonly deployed in motor control centers, industrial control panels, and power distribution systems where selective coordination and high fault current interruption are critical requirements.

Key Features & Specifications

• Type: Current-limiting time-delay fuse, RK1 class, single barrel construction
• Voltage Rating: 600V AC/DC
• Current Rating: 1A
• Dimensions: 5" L × 0.81" W × 0.81" H (127mm × 20.6mm × 20.6mm)
• Standards: Industrial low-voltage fuse standards
• Applications: Motor control centers, industrial control panels, power distribution systems
• AIC rating: 200kA @ 600V
• Class Rating: RK1
• Barrels: 1
• Diameter: 0.81 inches (20.6mm)
• Weight: 1 lb (0.45 kg)
• Family: LIMITRON
• Item Subcategory: Low Voltage Fuse

Product Identification

• UPC: 051712417006
• GTIN: 00051712417006
