Cooper Bussmann KBC-150 - Low Voltage Fuse 150A (200kA AIC @600V)

Cooper Bussmann KBC-150 is a low-voltage fuse designed for high-current circuit protection in industrial applications. Rated for 600V AC/DC systems with a 150A current capacity, it features a stud-mounted design with a single barrel construction and a compact form factor (1.58"L x 1.6"H x 4.61"W). This fuse meets rigorous industry standards with a 200kA interrupting capacity at 600V, providing reliable short-circuit protection. Its 0.41" diameter body with 1 lb weight makes it suitable for panelboards and switchgear in manufacturing plants and power distribution systems.

Key Features & Specifications

• Type: Low-voltage current-limiting fuse with stud connection
• Voltage Rating: 600V AC/DC
• Current Rating: 150A
• Dimensions: 1.58"L x 1.6"H x 4.61"W (40.1mm x 40.6mm x 117mm)
• AIC Rating: 200kA at 600V
• Connection: Stud terminal
• Barrels: 1
• Diameter: 0.41" (10.4mm)
• Weight: 1 lb (0.45kg)
• Standards: UL/CSA compliant
• Applications: Industrial switchgear, motor protection, power distribution

Product Identification

• UPC: 05171249150
• GTIN: 00051712491501
