Cooper Bussmann KAC-90 - Low Voltage Fuse 90A (200kA AIC @ 600V)

Cooper Bussmann KAC-90 is a low-voltage fuse designed for high-current circuit protection in industrial applications. It features a 600V AC/DC voltage rating and a 90A current rating, with a compact stud-mounted design measuring 1" (L) x 5" (H) x 1" (W) and 0.81" diameter. The fuse meets UL and CE standards with a 200kA interrupting capacity at 600V, constructed with durable materials for reliable operation in demanding environments including power distribution systems and heavy machinery.

Key Features & Specifications

• Type: Low-voltage current-limiting fuse with stud connection
• Voltage Rating: 600V AC/DC
• Current Rating: 90A
• Dimensions: 1" L x 5" H x 1" W (25.4mm x 127mm x 25.4mm)
• Standards: UL Recognized, CE Marked
• Applications: Industrial power distribution, motor protection
• AIC Rating: 200kA @ 600V
• Connection: Stud
• Barrels: 1
• Diameter: 0.81" (20.6mm)
• Weight: 1 lb (0.45kg)
• Country of Origin: Mexico

Product Identification

• UPC: 05171247090
• GTIN: 00051712470902
