Bussmann KAC-45 - Low Voltage Fuse 45A (200kA AIC @600V)

Bussmann KAC-45 is a low-voltage current-limiting fuse designed for industrial circuit protection applications. It features a 45A current rating and 600V voltage rating with exceptional 200kA interrupting capacity at rated voltage. The fuse measures 4.32 inches in height with a 0.76-inch diameter cylindrical body and utilizes stud-type connections with single-barrel construction. Certified to UL and CE standards, this fuse meets rigorous safety requirements for industrial electrical systems. Typical applications include motor circuit protection, transformer protection, and industrial control panel installations where high-fault current interruption is critical.

Key Features & Specifications

• Type: Low-voltage current-limiting fuse with stud connection, single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 45A
• Dimensions: 4.32" height × 0.76" width × 0.76" depth
• Standards: UL Recognized, CE Marked
• Applications: Industrial circuit protection, motor circuits, transformer protection
• AIC rating: 200kA@600V
• Connection: Stud
• Barrels: 1
• Diameter: 1 inch
• Weight: 1 lb
• Certification: UL Recognized, CE Marked

Product Identification

• UPC: 005171247045
• GTIN: 00051712470452
