Bussmann KAC-350 - Low Voltage Fuse 350A (200kA AIC @600V)

Bussmann KAC-350 is a low voltage fuse designed for industrial circuit protection applications requiring high interrupting capacity. The fuse features a 600V voltage rating with a 350A current rating, providing reliable overcurrent protection in demanding electrical environments. Constructed with stud connections and a single barrel design, the fuse measures 6.182 inches in length with a 2-inch diameter and weighs 1 lb. It carries UL Recognition and CE Marking, ensuring compliance with international safety standards for industrial electrical components. Typical applications include motor control centers, industrial control panels, and power distribution systems where high fault current interruption is critical.

Key Features & Specifications

• Type: KAC series low voltage fuse with stud connection, single barrel construction
• Voltage Rating: 600V
• Current Rating: 350A
• Dimensions: 6.182" L x 6.1" H x 2.1" W
• Standards: UL Recognized, CE Marked
• Applications: Industrial circuit protection, motor control centers, power distribution systems
• Connection: Stud
• Barrels: 1
• AIC rating: 200kA@600V
• Diameter: 2 inches
• Weight: 1 lb
• Certification: UL Recognized, CE Marked
• Family: KAC Series
• Country of Origin: Mexico

Product Identification

• UPC: 051712473507
• GTIN: 00051712473507
