Cooper Bussmann KAC-10 - Low Voltage Fuse 10A (200kA@600V Interrupt Rating)

Cooper Bussmann KAC-10 is a low-voltage fuse designed for high-interrupting capacity circuit protection in industrial applications. This 10A fuse features a 600V AC/DC voltage rating with a 200kA interrupting capacity at rated voltage, housed in a compact stud-mounted design measuring 0.5" (L) x 2.84" (H) x 0.5" (W) with a 0.56" diameter barrel. UL Recognized and CE Marked for compliance, the fuse is constructed for demanding environments including motor control centers, switchgear, and power distribution systems where reliable overcurrent protection is critical.

Key Features & Specifications

• Type: Low-voltage current-limiting fuse with stud connection
• Voltage Rating: 600V AC/DC
• Current Rating: 10A
• Dimensions: 0.5" x 2.84" x 0.5" (LxHxW)
• Standards: UL Recognized, CE Marked
• Applications: Industrial power distribution, motor protection
• AIC rating: 200kA@600V
• Connection: Stud
• Barrels: 1
• Diameter: 0.56"
• Weight: 1 lb
• Country of Origin: Mexico

Product Identification

• UPC: 05171247010
• GTIN: 00051712470100
