Eaton JHC-70 - Class J Fuse 600V AC (Current-Limiting Protection)

Eaton JHC-70 is a low-voltage current-limiting fuse designed for robust circuit protection in industrial power distribution systems. It features a 600V AC voltage rating with current ratings available across multiple ranges, housed in a compact cylindrical construction with specific dimensional characteristics for secure mounting. The fuse complies with relevant industry standards including UL/CSA certifications, ensuring reliable performance in demanding environments. Typical applications include motor circuit protection, transformer protection, and feeder circuit protection where high interrupting capacity is required.

Key Features & Specifications

• Type: Current-limiting fuse with ceramic body and silver-sand construction
• Voltage Rating: 600V AC
• Current Rating: Available in multiple ampere ratings
• Dimensions: Standard cylindrical fuse dimensions with specific mounting requirements
• Standards: UL/CSA certified
• Applications: Motor circuit protection, transformer protection, feeder circuits
• Fuse Class: J
• Mounting: Standard fuse clip mounting
• AIC rating: High interrupting capacity
• Weight: 0.33 lb
• Item Subcategory: Low Voltage

Product Identification

• Manufacturer: Eaton
• Model: JHC-70
