Edison Fuses JDL500 - Class JDL Fuse 500A 600V (300kA AIC)

Edison Fuses JDL500 is a Class J low-voltage fuse designed for high-interrupting circuit protection in industrial electrical systems. It features a 600V AC rating with a 500A current capacity and a 300kA interrupting rating at 600V AC for reliable short-circuit protection. The fuse has a compact bolt-in blade design with a 2.5-inch diameter and 8-inch length, constructed with durable materials for harsh environments. It complies with industry standards for Class J fuses and is commonly used in motor control centers, switchgear, and power distribution panels requiring high fault current protection.

Key Features & Specifications

• Type: Class JDL time-delay fuse with bolt-in blade connection
• Voltage Rating: 600V AC
• Current Rating: 500A
• Dimensions: 8"L x 2.5"W x 2.5"H
• Weight: 2 lb
• Diameter: 2.5 inches
• Standards: Class J fuse specifications
• Applications: Industrial power distribution, motor protection, switchgear
• AIC rating: 300kA@600Vac
• Connection: Bolt-In Blade
• Barrels: 1
• Velocity: D
• Country of Origin: Mexico

Product Identification

• UPC: 78263480361
• GTIN: 00782634803614
