Edison Fuses JDL400 - Class J Fuse 400A 600V (300kA AIC)

Edison Fuses JDL400 is a Class J low-voltage fuse designed for high-interrupting circuit protection in industrial electrical systems. Rated for 600V AC with a 400A current capacity, it features a bolt-in blade connection and delivers 300kA interrupting capacity at rated voltage. The fuse measures 7.13" in length with a 2.11" diameter, constructed to UL/ANSI standards for reliable performance in demanding environments. Its Class J time-delay characteristics make it suitable for motor circuits, transformers, and feeder protection where high fault currents may occur.

Key Features & Specifications

• Type: Class J time-delay fuse with bolt-in blade connection
• Voltage Rating: 600V AC
• Current Rating: 400A
• Dimensions: 7.13"L x 2.13"W x 2.13"H
• Weight: 1 lb
• Diameter: 2.11"
• AIC Rating: 300kA@600V AC
• Class Rating: J
• Connection: Bolt-In Blade
• Barrels: 1
• Velocity: D

Product Identification

• UPC: 78263480359
• GTIN: 00782634803591
