Eaton HPS Fuse - Current-Limiting Fuse 600V AC (200kA AIC, UL 248-10)

Eaton HPS Fuse is a current-limiting fuse designed for robust circuit protection in industrial power distribution systems. It features voltage ratings up to 600V AC and current ratings from 1A to 600A, with a compact cylindrical design constructed from durable ceramic bodies and silver-plated copper end caps. The fuse meets UL 248-10 and CSA standards for branch circuit protection, ensuring reliable operation in harsh environments. Typical applications include motor control centers, transformers, and heavy machinery where high interrupting capacity (200kA AIC) is required.

Key Features & Specifications

• Type: Current-limiting, ceramic-body fuse with silver-plated terminals
• Voltage Rating: 600V AC
• Current Rating: 1A–600A
• Dimensions: Varies by amperage (e.g., 30A: 2.25" L x 0.56" D)
• Standards: UL 248-10, CSA, IEC 60269
• Applications: Motor protection, transformers, industrial panels
• AIC Rating: 200kA
• Connection: Blade-type terminals
• Class Rating: RK1/RK5
• Operating Temperature: -40°C to 100°C
• Mounting: Clip-mounted or bolt-on
• Certification: UL Listed, CSA Certified
