Bussmann HLR-2A - Time-Delay Fuse 2A (600V AC/250V DC)

The Bussmann HLR-2A is a 2-ampere time-delay fuse designed to provide reliable circuit protection against overcurrent conditions in industrial control systems. It features a 600V AC/250V DC voltage rating and is engineered with a 1/4-inch diameter, single-barrel construction, measuring 0.87 in x 2-1/4 in x 0.87 in and weighing 5.19 lb. This fuse is UL Listed and CSA Certified, ensuring compliance with North American safety standards for electrical components. It is typically utilized within fuse holders to safeguard motors, transformers, and solenoid coils from damaging overloads and short circuits.

Key Features & Specifications

• Type: Time-Delay Fuse, Single Barrel
• Voltage Rating: 600V AC / 250V DC
• Current Rating: 2A
• Dimensions: 0.87 in x 2-1/4 in x 0.87 in (22.1 mm x 57.2 mm x 22.1 mm)
• Diameter: 0.25 in (6.35 mm)
• Weight: 5.19 lb
• Standards: UL Listed, CSA Certified
• Applications: Protection for motors, transformers, and solenoids in industrial control circuits
• Barrels: 1
• Certification: CSA Certified, UL Listed
• Section: Fuse Holders
• Country of Origin: United States

Product Identification

• UPC: 051712567466
