Edison Fuses HCTR2 - Class CC Fuse 2A 600V (200kA AIC)

Edison Fuses HCTR2 is a Class CC low-voltage fuse designed for circuit protection in industrial electrical systems. Rated for 600V AC/DC applications with a 2A current capacity, it features a compact cylindrical design (1" length × 0.406" diameter) constructed with durable materials for reliable operation. This UL-recognized fuse meets industry standards with a 200kA interrupting capacity at 600V, making it suitable for motor control centers, panelboards, and other high-fault current environments requiring precise overcurrent protection.

Key Features & Specifications

• Type: Class CC cylindrical fuse, single-barrel construction
• Voltage Rating: 600V AC/DC
• Current Rating: 2A
• Dimensions: 1" L × 0.406" W × 0.406" H (25.4mm × 10.3mm × 10.3mm)
• Standards: UL 248-4 recognized
• Applications: Industrial control circuits, motor protection, panelboards
• AIC rating: 200kA@600V
• Class Rating: CC
• Weight: 1.1 lb (0.5 kg)
• Diameter: 0.41" (10.4mm)

Product Identification

• UPC: 782634802150
• GTIN: 00782634802150
