Edison Fuses HCLR5 - Class CC Fuse 5A@600V (200kA AIC)

Edison Fuses HCLR5 is a Class CC low-voltage fuse designed for circuit protection in industrial electrical systems. It features a 600V AC rating with a 5A current capacity and 200kA interrupting rating at 600V for reliable overcurrent protection. The compact cylindrical design measures 1" x 0.406" x 0.406" (LxWxH) with a 0.41" diameter, constructed as a single-barrel fuse weighing 1.1 lb. This UL-recognized component meets industry standards for protection of control circuits, transformers, and motor loads in commercial/industrial applications.

Key Features & Specifications

• Type: Class CC low-voltage current-limiting fuse
• Voltage Rating: 600V AC
• Current Rating: 5A
• Dimensions: 1" L x 0.406" W x 0.406" H
• Standards: UL Recognized
• Applications: Industrial control circuits, transformers, motor loads
• AIC rating: 200kA@600V
• Diameter: 0.41"
• Barrels: 1
• Weight: 1.1 lb
• Class Rating: CC

Product Identification

• UPC: 78263442064
• GTIN: 00782634420644
