Edison Fuses HCLR1.5 - Class CC Fuse 1.5A (200kA@600V Interrupt Rating)

Edison Fuses HCLR1.5 is a Class CC low-voltage fuse designed for circuit protection in industrial electrical systems. It features a 600V AC rating with a 1.5A current capacity and a high interrupting rating of 200kA at 600V for reliable overload protection. The compact cylindrical design measures 1" in length with a 0.41" diameter, constructed with a single barrel configuration and weighing 1.001 lb. This fuse meets industry standards for Class CC fuses, suitable for panelboards, control circuits, and transformer protection applications where precise current limitation is critical.

Key Features & Specifications

• Type: Class CC low-voltage current-limiting fuse
• Voltage Rating: 600V AC
• Current Rating: 1.5A
• Dimensions: 1" L × 0.406" W × 0.406" H (25.4mm × 10.3mm × 10.3mm)
• Diameter: 0.41" (10.4mm)
• Weight: 1.001 lb (0.454 kg)
• AIC Rating: 200kA at 600V
• Barrels: 1
• Standards: Class CC fuse specifications
• Applications: Industrial control circuits, panelboards, transformer protection

Product Identification

• UPC: 78263442059
• GTIN: 00782634420590
