Edison Fuses HCLR1 - Class CC Fuse 1A 600V (200kA AIC)

Edison Fuses HCLR1 is a Class CC low-voltage fuse designed for circuit protection in industrial electrical systems. It features a 600V AC/DC voltage rating and 1A current rating with a compact 1" × 0.406" × 0.406" (25.4mm × 10.3mm × 10.3mm) ceramic body construction providing 200kA interrupting capacity at rated voltage. The fuse meets industry standards for Class CC protection with single-barrel design and 0.41" (10.4mm) diameter terminals, suitable for motor control centers, transformers, and power distribution equipment requiring precise overcurrent protection.

Key Features & Specifications

• Type: Class CC time-delay fuse with ceramic body
• Voltage Rating: 600V AC/DC
• Current Rating: 1A
• Dimensions: 1" L × 0.406" W × 0.406" H (25.4mm × 10.3mm × 10.3mm)
• Weight: 1.1 lb
• Diameter: 0.41" (10.4mm)
• AIC Rating: 200kA@600V
• Barrels: 1
• Class Rating: CC
• Standards: UL/CSA recognized
• Applications: Motor controls, transformers, power distribution panels

Product Identification

• UPC: 78263442058
• GTIN: 00782634420583
