Mersen H300089CF00 - Medium Voltage Fuse 5500V 800A (H-Type Bolt-In)

Mersen H300089CF00 is a medium voltage current-limiting fuse designed for robust circuit protection in industrial power distribution systems. It features a 5500V voltage rating and 800A current rating, providing reliable overcurrent protection for high-power applications. The fuse construction incorporates four barrels with a 1.5-inch diameter and utilizes bolt-in connection technology, weighing 43 pounds for substantial industrial mounting. This H-type fuse complies with relevant industry standards for medium voltage protection equipment. Typical applications include motor control centers, transformer protection, and industrial power distribution systems where high interrupting capacity is required.

Key Features & Specifications

• Type: H-type medium voltage current-limiting fuse with four-barrel construction
• Voltage Rating: 5500V AC
• Current Rating: 800A
• Dimensions: 1.5-inch diameter
• Connection: Bolt-in termination
• Weight: 43 lb
• Barrels: 4
• Fuse Class: H
• Item Subcategory: Medium Voltage
• Standards: Industrial medium voltage protection standards
• Applications: Industrial power distribution, motor control centers, transformer protection

Product Identification

• GTIN: 00782001267698
