Cutler Hammer GSA6/10 - GSA Series Time-Delay Fuse 6A 250V (35kA AIC)
Regular price
$7.84
$7.84
Regular price
$7.04
$7.04
Sale price
$7.84
$7.84
Save $-0.80
/
- Low stock - 2 items left
- Backordered, shipping soon
The Cutler Hammer GSA6/10 is a low voltage current-limiting fuse designed to provide reliable circuit protection for industrial electrical systems. It features a 6A current rating and a 250V voltage rating, offering an interrupting rating of 35,000 amperes at 250V AC. Constructed with a single-barrel, ferrule connection design and a 14mm diameter, this time-delay fuse is engineered to withstand temporary overloads without nuisance opening while providing fast response to short-circuit faults. This fuse complies with industry standards for safety and performance in demanding environments, making it suitable for protecting motor circuits, transformers, and feeder circuits where high fault current interruption is critical.
Key Features & Specifications
Product Identification
Key Features & Specifications
- Type: GSA Series, Low Voltage Current-Limiting Time-Delay Fuse, Ferrule Connection
- Voltage Rating: 250V AC
- Current Rating: 6A
- Dimensions: 14mm Diameter
- Standards: Industry Standard for Low Voltage Fuse Protection
- Applications: Motor Circuits, Transformers, Feeder Circuit Protection
- AIC Rating: 35,000A @ 250V AC
- Connection: Ferrule
- Barrels: 1
- Velocity: Time-Delay
- Weight: 5.19 lb
Product Identification
- UPC: 78200181038
- GTIN: 00782001810382
