Cutler Hammer GSA3/16 - Time-Delay Fuse 3A (35kA AIC, 250V)

The Cutler Hammer GSA3/16 is a low-voltage, time-delay fuse designed to provide reliable circuit protection for motor circuits and other applications with high inrush currents. It features a 3A current rating and a 250V AC voltage rating, with an interrupting rating of 35,000 amperes at 250V AC to safely clear high-level faults. Constructed with a single-barrel design and 14mm diameter ferrule connections, this fuse is built for durability and secure installation in industrial environments. It complies with industry standards for time-delay fuses, ensuring coordinated protection that prevents nuisance tripping during normal motor start-up. Typical applications include the protection of motors, transformers, and solenoids where sustained overload conditions are expected.

Key Features & Specifications

• Type: GSA Series, Time-Delay, Single Barrel, Low-Voltage Fuse
• Voltage Rating: 250V AC
• Current Rating: 3A
• AIC rating: 35,000A @ 250V AC
• Connection: Ferrule
• Diameter: 14 mm
• Barrels: 1
• Weight: 5.19 lb
• Item Subcategory: Low Voltage
• Family: GSA Series
