Cutler Hammer GDG5 - Low Voltage Fuse 5A 250V (50kA AIC Rating)

The Cutler Hammer GDG5 is a low-voltage current-limiting fuse designed for circuit protection in industrial applications. It features a 250V voltage rating with a 5A current rating and 50kA interrupting capacity at 250V AC. The fuse employs a compact ferrule connection design with 5mm diameter and 20mm length construction. It complies with UL Listed and CSA Certified safety standards for reliable operation. Typical applications include protection of control circuits, transformers, and motor circuits in industrial environments.

Key Features & Specifications

• Type: GDG series low-voltage current-limiting fuse with ferrule connection
• Voltage Rating: 250V AC
• Current Rating: 5A
• Dimensions: 5mm diameter × 20mm length
• Standards: UL Listed, CSA Certified
• Applications: Industrial control circuits, transformers, motor protection
• AIC rating: 50kA@250V AC
• Connection: Ferrule
• Fuse Class: GDG
• Mounting: Ferrule connection
• Certification: UL Listed, CSA Certified
• Family: GDG Series
• Weight: 5 lb
• Country of Origin: China

Product Identification

• UPC: 782001764470
• GTIN: 00782001764470
