Cooper Bussmann FWX-225A - Low Voltage Fuse 225A (200kA AIC @250V)

Cooper Bussmann FWX-225A is a low-voltage current-limiting fuse designed for high-interrupting-capacity circuit protection in industrial electrical systems. Rated for 250V AC/DC operation with a 225A current capacity, it features a stud-mounted design with a single-barrel construction and 200kA interrupting rating at 250V for reliable fault protection. The compact 4.3" x 1.63" x 1.62" (LxHxW) fuse body with 1.5" diameter meets demanding space constraints while maintaining robust performance. Compliant with industry standards for low-voltage protection devices, it is commonly deployed in motor control centers, switchgear, and power distribution panels requiring high-fault current interruption.

Key Features & Specifications

• Type: FWX series current-limiting fuse with stud connection
• Voltage Rating: 250V AC/DC
• Current Rating: 225A
• Dimensions: 4.3" L x 1.63" H x 1.62" W (109.2mm x 41.4mm x 41.1mm)
• Weight: 1 lb (0.45 kg)
• Diameter: 1.5" (38.1mm)
• AIC Rating: 200kA @ 250V
• Connection: Stud terminal
• Barrels: Single
• Standards: Industrial low-voltage fuse compliance
• Applications: Motor controls, switchgear, power distribution

Product Identification

• UPC: 051712153973
• GTIN: 00051712153973
