Cooper Bussmann FWH-325A - Low Voltage Fuse 325A (200kA AIC @ 500V)

Cooper Bussmann FWH-325A is a low-voltage fuse designed for high-current circuit protection in industrial applications. It features a 500V AC/DC voltage rating and 325A current capacity, housed in a compact stud-mounted design with dimensions of 1.69"L × 1.61"H × 4.52"W and 2" diameter. The fuse meets UL, CSA, RoHS, and CE standards with a 200kA interrupting capacity at 500V, ensuring reliable protection in demanding environments like power distribution systems and heavy machinery.

Key Features & Specifications

• Type: Low-voltage current-limiting fuse with stud connection
• Voltage Rating: 500V AC/DC
• Current Rating: 325A
• Dimensions: 1.69"L × 1.61"H × 4.52"W (43mm × 41mm × 115mm)
• Weight: 1 lb (0.45 kg)
• Diameter: 2" (51mm)
• Standards: UL Recognized, CSA Certified, RoHS Compliant, CE Marked
• AIC Rating: 200kA @ 500V
• Connection: Stud
• Barrels: 1
• Country of Origin: Mexico

Product Identification

• UPC: 005171215378
• GTIN: 00051712153782
