Bussmann FWH-225A - FWH Series Fuse 225A (200kA@500V AIC Rating)

Bussmann FWH-225A is a low voltage fuse designed for industrial circuit protection applications requiring high interrupting capacity. This fuse features a 225A current rating with a 500V voltage rating and provides 200kA interrupting capacity at 500V for reliable short-circuit protection. Constructed with stud connections and a single barrel design, the fuse measures 1.5 inches in diameter with a 4-11/32 inch length and weighs 1 lb. It meets CE, CSA, and UL recognition standards for industrial safety compliance. Typical applications include industrial control panels, motor circuits, and power distribution systems where high fault current protection is essential.

Key Features & Specifications

• Type: FWH series low voltage fuse with stud connection, single barrel construction
• Voltage Rating: 500V AC/DC
• Current Rating: 225A
• Dimensions: 1.5" diameter × 4-11/32" length
• Standards: CE, CSA Certified, UL Recognized
• Applications: Industrial control panels, motor protection, power distribution systems
• AIC rating: 200kA@500V
• Connection: Stud
• Barrels: 1
• Weight: 1 lb
• Certification: CE, CSA Certified, UL Recognized
• Family: FWH Series
• Country of Origin: Mexico

Product Identification

• UPC: 051712153751
• GTIN: 00051712153751
