Cooper Bussmann FRN-R-8ID - RK5 Fuse 8A 250V (200kA AIC)

Cooper Bussmann FRN-R-8ID is a low-voltage current-limiting fuse designed for circuit protection in industrial electrical systems. This RK5-class fuse features a 250V AC rating with an 8A current capacity and 200kA interrupting rating at 250V for high-fault protection. The cylindrical fuse measures 1.06" in diameter with a 2" body length, constructed with a single-barrel design and weighing 1.32 lb. It meets UL 248-12 (Guide JDDZ), CSA Class 1422-01, and CE standards for safety compliance. Typical applications include motor control centers, panelboards, and industrial power distribution systems requiring reliable overcurrent protection.

Key Features & Specifications

• Type: Current-limiting fuse, RK5 class, single-barrel construction
• Voltage Rating: 250V AC
• Current Rating: 8A
• Dimensions: 2" length x 1.06" diameter
• Standards: UL 248-12 (JDDZ), CSA 1422-01, CE
• Applications: Industrial power distribution, motor protection, panelboards
• AIC rating: 200kA@250V
• Class Rating: RK5
• Weight: 1.32 lb
• Country of Origin: Mexico

Product Identification

• UPC: 05171220432
• GTIN: 00051712204323
