Bussmannn FNQ-R-1-6/10 - Class CC Fuse 600V/1A (200kA AIC Rating)

Bussmannn FNQ-R-1-6/10 is a Class CC low-voltage fuse designed for circuit protection in industrial applications. It features a 600V AC rating with a 1A current capacity and 200kA interrupting rating at 600V for reliable overcurrent protection. The fuse has a compact 1-1/2" length with 0.41" diameter construction using durable materials for harsh environments. It meets CE/UL-248-4 and CSA Class 1422-01 standards for safety compliance. Typical applications include motor control centers, industrial control panels, and power distribution systems requiring Class CC protection.

Key Features & Specifications

• Type: FNQ Class CC time-delay fuse with single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 1A
• Dimensions: 1-1/2" length x 0.41" diameter
• Weight: 1 lb
• Standards: CE/UL-248-4 Guide JDDZ, CSA Class 1422-01
• Applications: Motor controls, industrial panels, power distribution
• AIC rating: 200kA@600V
• Class Rating: CC
• Barrels: 1
• Country of Origin: Mexico

Product Identification

• UPC: 051712496964
• GTIN: 00051712496964
