Bussmann FNM-5-6/10 - Low Voltage Fuse 5A 250V (200kA AIC Rating)

Bussmann FNM-5-6/10 is a low voltage fuse designed for circuit protection in industrial applications. It features a 5A current rating and 250V voltage rating with 200kA interrupting capacity at rated voltage. The fuse measures 1-1/2 inches in length with 0.41 inch diameter ferrule non-rejection connections and single barrel construction. It complies with CE, CSA Class 1422-01, and UL-248-14 Guide JDYX standards for safety and performance. This fuse is typically used in industrial control circuits, motor branch circuits, and feeder protection applications requiring reliable overcurrent protection.

Key Features & Specifications

• Type: FNM Series low voltage fuse with ferrule non-rejection connection, single barrel construction
• Voltage Rating: 250V AC
• Current Rating: 5A
• Dimensions: 1-1/2 inch length x 0.41 inch diameter
• Standards: CE, CSA Class 1422-01, UL-248-14 Guide JDYX
• Applications: Industrial control circuits, motor branch circuits, feeder protection
• AIC rating: 200kA@250V
• Connection: Ferrule Non-Rejection
• Barrels: 1
• Class Rating: 1422-01
• Diameter: 0.41 inch
• Weight: 1 lb
• Certification: CE, CSA Class 1422-01, UL-248-14 Guide JDYX

Product Identification

• UPC: 051712520560
• GTIN: 00051712520560
