Edison Fuses EDCC5 - Class CC Fuse 5A@600V (200kA AIC)

Edison Fuses EDCC5 is a Class CC low-voltage fuse designed for circuit protection in industrial electrical systems. It features a 600V AC/DC voltage rating and 5A current rating with a high interrupting capacity of 200kA at 600V. The compact cylindrical design measures 1.5" (38.1mm) in length with a 0.41" (10.4mm) diameter, constructed for reliable performance in tight spaces. This UL-recognized fuse meets industry standards for overcurrent protection in control circuits, motor loads, and transformer applications.

Key Features & Specifications

• Type: Class CC cylindrical ferrule fuse with single barrel construction
• Voltage Rating: 600V AC/DC
• Current Rating: 5A
• Dimensions: 1.5" L × 0.41" W × 0.41" H (38.1 × 10.4 × 10.4mm)
• Standards: UL 248-4 recognized
• Applications: Control circuits, transformers, motor loads
• AIC rating: 200kA@600V
• Diameter: 0.41" (10.4mm)
• Weight: 1.19 lb
• Class Rating: CC

Product Identification

• UPC: 78263480817
• GTIN: 00782634808176
