Edison Fuses EDCC15 - RK5 Time-Delay Fuse 15A 600V (200kA AIC)

Edison Fuses EDCC15 is a low-voltage RK5 class fuse designed for circuit protection in industrial electrical systems. It features a 600V AC/DC voltage rating and 15A current rating with a compact 1.5" x 0.41" x 0.41" (38.1mm x 10.4mm x 10.4mm) ceramic body construction. The single-barrel design meets UL/CSA standards and provides 200kA interrupting capacity at 600V for reliable short-circuit protection. Typical applications include motor control centers, panelboards, and industrial power distribution equipment requiring time-delay fuse characteristics.

Key Features & Specifications

• Type: RK5 time-delay fuse with ceramic body construction
• Voltage Rating: 600V AC/DC
• Current Rating: 15A
• Dimensions: 1.5" L x 0.41" W x 0.41" H (38.1mm x 10.4mm x 10.4mm)
• Standards: UL/CSA listed
• Applications: Industrial power distribution, motor protection, panelboards
• Class Rating: RK5
• Barrels: 1
• AIC rating: 200kA@600V
• Diameter: 0.56" (14.2mm)
• Weight: 1.19 lb

Product Identification

• UPC: 78263480827
• GTIN: 00782634808275
