Edison Fuses EDCC10 - Class CC Fuse 10A@600V (200kA AIC)

Edison Fuses EDCC10 is a low-voltage Class CC fuse designed for circuit protection in industrial electrical systems. It features a 600V AC/DC voltage rating and 10A current rating with a compact 1.5" × 0.41" × 0.41" (L×W×H) ceramic body construction. The fuse meets industry standards with a 200kA interrupting capacity at 600V and CC classification for fast-acting protection. Typical applications include motor control centers, transformers, and power distribution equipment requiring reliable overcurrent protection.

Key Features & Specifications

• Type: EDCC Series fast-acting ceramic fuse
• Voltage Rating: 600V AC/DC
• Current Rating: 10A
• Dimensions: 1.5" L × 0.41" W × 0.41" H (38.1 × 10.4 × 10.4mm)
• Standards: Class CC rated
• Applications: Industrial power distribution, motor protection
• AIC rating: 200kA@600V
• Diameter: 0.41" (10.4mm)
• Barrels: 1
• Weight: 1.19 lb

Product Identification

• UPC: 782634808251
• GTIN: 00782634808251
