Edison Fuses ECSR20 - Class E Fuse 20A 600V (200kA AIC)

Edison Fuses ECSR20 is a Class E low-voltage fuse designed for circuit protection in industrial electrical systems. This 600VAC-rated fuse features a 20A current rating with a 200kA interrupting capacity at 600V, housed in a durable ferrule-connected single-barrel construction measuring 3" in diameter and 9.63" in length. Compliant with industry standards for Class E fuses, it provides reliable overcurrent protection for motor circuits, transformers, and feeder lines in commercial and industrial power distribution systems.

Key Features & Specifications

• Type: Class E time-delay fuse with ferrule connection
• Voltage Rating: 600V AC
• Current Rating: 20A
• Dimensions: 3" diameter x 9.63" length
• Standards: Class E fuse compliance
• Applications: Motor protection, transformer circuits, industrial feeders
• AIC rating: 200kA@600V
• Connection: Ferrule
• Barrels: 1
• Weight: 2.5 lb
• Country of Origin: United States

Product Identification

• UPC: 78263450832
• GTIN: 00782634508328
