Edison Fuses ECNR60 - RK5 Current-Limiting Fuse 60A@250V (200kA AIC)

Edison Fuses ECNR60 is a low-voltage current-limiting fuse designed for circuit protection in industrial electrical systems. Rated for 250V AC with a 60A current capacity, it features an RK5 class rating and provides 200kA interrupting capacity at rated voltage. The cylindrical fuse measures 10.38" in length with a 0.81" diameter, constructed with durable materials for reliable operation in demanding environments. Compliant with industry standards for low-voltage protection devices, this fuse is commonly used in panelboards, switchgear, and motor control centers where high fault current interruption is required.

Key Features & Specifications

• Type: ECNR series current-limiting fuse, RK5 class
• Voltage Rating: 250V AC
• Current Rating: 60A
• Dimensions: 10.38" L × 2.88" W × 2.88" H
• Weight: 4.15 lb
• Diameter: 0.81"
• Barrels: 1
• AIC Rating: 200kA @ 250V
• Standards: UL/CSA compliant
• Applications: Industrial panelboards, switchgear, motor protection

Product Identification

• UPC: 782634507390
• GTIN: 00782634507390
