Edison Fuses ECNR6 - RK5 Time-Delay Fuse 6A (200kA AIC @250V)

Edison Fuses ECNR6 is a low-voltage RK5 class fuse designed for circuit protection in industrial electrical systems. This 250VAC/DC-rated fuse features a 6A current rating with a 200kA interrupting capacity at 250V, housed in a compact ferrule-style construction measuring 2" x 0.56" x 0.56" (LxWxH) with a 1.06" diameter. The single-barrel design meets industry standards for time-delay protection in motor circuits and transformer applications, commonly used in panelboards, switchgear, and industrial control equipment.

Key Features & Specifications

• Type: RK5 time-delay fuse with ferrule connection
• Voltage Rating: 250V AC/DC
• Current Rating: 6A
• Dimensions: 2" L x 0.56" W x 0.56" H (50.8mm x 14.2mm x 14.2mm)
• Weight: 1.5 lb (0.68 kg)
• Diameter: 1.06" (26.9mm)
• Standards: UL/CSA listed
• Applications: Motor circuits, transformers, industrial controls
• Class Rating: RK5
• Connection: Ferrule
• Barrels: 1
• AIC rating: 200kA@250V

Product Identification

• UPC: 078263450698
• GTIN: 00782634506980
