Eaton DS35 - Class J Time-Delay Fuse 600V AC (200kA Interrupting Rating)

Eaton DS35 is a Class J time-delay fuse designed for branch circuit protection in industrial power distribution systems. It features a 600V AC voltage rating with current ratings from 0A to 600A, housed in a compact 30mm x 85mm ceramic body with silver-plated end caps for reliable conductivity. The fuse meets UL/CSA/ANSI standards and offers 200kA interrupting capacity for high-fault environments. Typical applications include motor protection, transformer circuits, and feeder protection in manufacturing facilities and commercial buildings.

Key Features & Specifications

• Type: Class J time-delay fuse with ceramic body and silver-plated terminals
• Voltage Rating: 600V AC
• Current Rating: 0A-600A
• Dimensions: 30mm diameter x 85mm length
• Standards: UL 248-8, CSA C22.2 No. 248.8, ANSI C97.1
• Applications: Motor circuits, transformers, feeders, industrial power distribution
• Interrupting Rating: 200kA
• Time Delay: 10 seconds at 500% rated current
• Terminal Type: Knife-blade
• Operating Temperature: -50°C to +125°C
• Material: Ceramic body with quartz sand filler

Product Identification

• UPC: 78227422550
• GTIN: 00782274225500
