Eaton DS171 - Class CC Fuse 600V AC/30A (200kA Interrupt Rating)

Eaton DS171 is a high-performance fuse designed for industrial circuit protection, featuring a 600V AC/250V DC rating with current ratings up to 30A for reliable overcurrent protection. Its compact cylindrical design (1.5" x 0.5") utilizes durable ceramic construction with silver-plated end caps for optimal conductivity and arc suppression. The fuse meets UL/CSA standards and is rated for operation in temperatures from -40°C to 125°C, making it suitable for motor controls, power distribution panels, and heavy equipment applications.

Key Features & Specifications

• Type: Ceramic body time-delay fuse with sand-filled arc quenching
• Voltage Rating: 600V AC / 250V DC
• Current Rating: 30A (5A-30A range available)
• Dimensions: 1.5" length x 0.5" diameter
• Standards: UL 248-14, CSA C22.2 No. 248.14
• Applications: Motor branch circuits, transformers, industrial controls
• Class Rating: Class CC
• Interrupt Rating: 200kA at 600V AC
• Temperature Range: -40°C to 125°C
• Weight: 2.98 lb

Product Identification

• UPC: 782274511948
• GTIN: 00662283014930
