Eaton D7PR23T - Class J Fuse 23A 600V (200kA Interrupt Rating)

Eaton D7PR23T is a current-limiting fuse designed for robust circuit protection in industrial power distribution systems. Rated for 600V AC with a 23A current capacity, it features a compact cylindrical design with durable ceramic body construction and silver-element fuse links for reliable operation. The fuse meets UL 248-10 and CSA standards for branch circuit protection, ensuring compliance with North American safety requirements. Typical applications include motor control centers, transformers, and feeder circuits where high interrupting capacity (200kA) is critical for fault protection.

Key Features & Specifications

• Type: Current-limiting Class J fuse with ceramic body and silver-element construction
• Voltage Rating: 600V AC
• Current Rating: 23A
• Dimensions: 60mm length x 22mm diameter
• Standards: UL 248-10, CSA certified
• Applications: Industrial power distribution, MCCs, transformer protection
• Interrupting Rating: 200kA
• Weight: 0.63 lb

Product Identification

• UPC: 782114000000
