Eaton D7PR1P1 - Class J Fuse 1A 600V (200kA Interrupt Rating)

Eaton D7PR1P1 is a current-limiting fuse designed for overcurrent protection in industrial electrical systems. It features a 600V AC rating with a 1A current capacity, housed in a compact 10.3mm diameter x 38.1mm length ceramic body with silver-plated end caps for reliable conductivity. The fuse meets UL 248-14 and CSA standards for branch circuit protection, with a 200kA interrupting rating for high-fault environments. Typical applications include motor control centers, transformers, and power distribution equipment requiring precise current interruption.

Key Features & Specifications

• Type: Current-limiting Class J fuse with ceramic body and silver-plated terminals
• Voltage Rating: 600V AC
• Current Rating: 1A
• Dimensions: 10.3mm diameter x 38.1mm length
• Standards: UL 248-14, CSA certified
• Applications: Motor protection, transformer circuits, power distribution
• Interrupting Rating: 200kA
• Weight: 0.4 lb
• Termination: Blade-style contacts
• Operating Temperature: -40°C to 100°C

Product Identification

• UPC: 782114000000
