Eaton D26MC4 - Class J Time-Delay Fuse 26A 600V (200kA Interrupt Rating)

Eaton D26MC4 is a current-limiting fuse designed for robust circuit protection in industrial power distribution systems. It features a 600V AC voltage rating and 26A current capacity with a compact 10.3mm diameter ceramic body construction for high interrupting capacity. The fuse meets UL 248-14 standards with Class J performance characteristics, ensuring reliable protection against short circuits and overloads. Its silver-element design provides precise time-delay operation, making it ideal for motor branch circuits, transformers, and feeder protection in commercial/industrial facilities.

Key Features & Specifications

• Type: Class J time-delay fuse with ceramic body and silver-element construction
• Voltage: 600V AC
• Current: 26A
• Dimensions: 10.3mm diameter x 38.1mm length
• Standards: UL 248-14, CSA certified
• Applications: Motor circuits, transformers, industrial feeders
• Interrupt Rating: 200kA
• Weight: 2.2 lb
• Temperature Rating: -50°C to +125°C

Product Identification

• UPC: 782113000000
