Cutler Hammer ATQR30 - Class CC Fuse 30A 600V (200kA AIC Rating)

Cutler Hammer ATQR30 is a Class CC low-voltage current-limiting fuse designed for branch circuit and component protection in industrial electrical systems. It features a 600V AC voltage rating with 30A current rating and provides 200kA interrupting capacity at rated voltage for reliable fault protection. The fuse construction utilizes a single-barrel design measuring 1-1/2 inches in length with 0.41-inch diameter and weighs 5 lb, engineered for compact panel space utilization. Certified to UL/CSA standards, this Amp-Trap 2000 series fuse meets rigorous industry requirements for safety and performance. Typical applications include protection of control transformers, motor controllers, and industrial control circuits where current limitation and high interrupting ratings are critical.

Key Features & Specifications

• Type: Class CC current-limiting fuse, single barrel design
• Voltage Rating: 600V AC
• Current Rating: 30A
• Dimensions: 1-1/2 inch length, 0.41 inch diameter
• Standards: UL/CSA certified
• Applications: Branch circuit protection, control transformers, motor controllers
• AIC rating: 200kA@600V
• Class Rating: CC
• Barrels: 1
• Weight: 5 lb
• Family: Amp-Trap 2000
• Country of Origin: Mexico

Product Identification

• UPC: 782001904722
• GTIN: 00782001904722
