Cutler Hammer ATQ5 - Current-Limiting Fuse 5A (10kA@500V AIC Rating)
Regular price
$10.37
$10.37
Regular price
$856.93
$856.93
Sale price
$10.37
$10.37
Save $846.56
/
- In stock, ready to ship
- Backordered, shipping soon
Cutler Hammer ATQ5 is a current-limiting fuse designed for protecting electrical circuits and equipment from short-circuit conditions. It features a 500V AC voltage rating and 5A current rating with a 10kA interrupting capacity at 500V. The fuse measures 1-1/2 inches in length with a 0.41-inch diameter in a single-barrel midget class construction. It complies with UL and CSA standards for industrial safety requirements. Typical applications include motor control centers, panelboards, and industrial control circuits where reliable overcurrent protection is essential.
Key Features & Specifications
Product Identification
Key Features & Specifications
- Type: Current-limiting fuse, single barrel, midget class
- Voltage Rating: 500V AC
- Current Rating: 5A
- Dimensions: 1-1/2 inches length, 0.41 inches diameter
- Standards: UL, CSA certified
- Applications: Motor control centers, panelboards, industrial control circuits
- AIC rating: 10kA@500V
- Class Rating: Midget
- Barrels: 1
- Weight: 5 lb
- Family: Amp-Trap
Product Identification
- UPC: 782001904265
- GTIN: 00782001904265
