Eaton Cutler-Hammer ATMR3/10 - Class CC Fuse 3A 600V (200kA AIC)

Eaton Cutler-Hammer ATMR3/10 is a Class CC low-voltage current-limiting fuse designed for branch circuit protection in industrial control panels and motor circuits. It features a 600V AC voltage rating with a 3A current rating, providing reliable overcurrent protection in demanding applications. The fuse construction utilizes a single-barrel design measuring 1-1/2 inches in length with a 0.41-inch diameter and weighs 0.02 lb, featuring current-limiting technology to protect against short-circuit currents. Certified to UL/CSA standards, this Amp-Trap series fuse offers 200kA interrupting rating at 600V AC, ensuring compliance with industrial safety requirements. Typical applications include protection of control transformers, solenoids, and other sensitive electronic components where high interrupting capacity and current limitation are essential.

Key Features & Specifications

• Type: Class CC current-limiting fuse, single barrel
• Voltage Rating: 600V AC
• Current Rating: 3A
• Dimensions: 1-1/2 inch length, 0.41 inch diameter
• Weight: 0.02 lb
• Standards: UL/CSA certified
• Applications: Industrial control panels, motor circuits, control transformers
• AIC rating: 200kA @ 600V AC
• Class Rating: CC
• Barrels: 1
• Family: Amp-Trap
• Country of Origin: Mexico

Product Identification

• UPC: 782001903404
• GTIN: 00782001903404
