Eaton Cutler-Hammer ATMR1-1/4 - Class CC Fuse 1A 600V (200kA AIC)

Eaton Cutler-Hammer ATMR1-1/4 is a Class CC low-voltage current-limiting fuse from the Amp-Trap family, designed to provide superior short-circuit protection for control circuits and transformers. It features a 1A current rating and 600V AC voltage rating with an impressive 200kA interrupting capacity at 600V AC. The fuse is constructed as a single-barrel design with compact physical dimensions of 1-1/2 inches in length and 0.41 inches in diameter, weighing only 0.02 lb. This component meets UL/CSA certification standards and is manufactured in Mexico for reliable industrial performance. Typical applications include protection of control circuits, small motors, and transformers where space constraints and high fault current protection are critical considerations.

Key Features & Specifications

• Type: Class CC current-limiting fuse, single barrel design
• Voltage Rating: 600V AC
• Current Rating: 1A
• Dimensions: 1-1/2 inches length, 0.41 inches diameter
• Standards: UL/CSA certified
• Applications: Control circuits, transformers, small motor protection
• AIC rating: 200kA@600V AC
• Family: Amp-Trap
• Weight: 0.02 lb
• Barrels: 1
• Class Rating: CC
• Country of Origin: Mexico

Product Identification

• UPC: 782001901042
• GTIN: 00782001901042
